Manual – MOVI-PLC® advanced DHE41B/DHF41B/DHR41B Controller
4
Installing the MOVI-PLC® advanced DHR41B controller
Mounting/Installation Instructions
LED Link /
Activity
The two LEDs Link (green) and Activity (yellow), integrated in the RJ45 plug connec-
tors (X30-1, X30-2), display the status of the Ethernet connection.
63365AXX
LED / Status Meaning
Link / Green There is an Ethernet connection.
Activity / Yel-
low
Data is currently being exchanged via Ethernet.
Link / Off There is no Ethernet connection.
X30-1
X30-2
LED "Link"
LED "Activity"
