Manual – MOVI-PLC® advanced DHE41B/DHF41B/DHR41B Controller
63
7
MOVI-PLC® advanced DHE41B controller
Technical Data and Dimension Drawings
RS485 interface COM1/2
X34:1 ... X34:6
One DOP11A operator panel or one gearmotor with integrated MOVIMOT
®
frequency inverter can be
connected per RS485 interface.
I/O standard, 57.6 / 9.6 kBaud, max. total cable length 200 m
Dynamic terminating resistor with fixed installation
COM 2 is isolated from the MOVI-PLC
®
advanced controller
SD memory card
OMH41B-T0...T10
PC readable
•Includes:
–Firmware
IEC program
–Data
At least 128 MB memory
Engineering Engineering is performed via the Ethernet 2 interface (X37).
The engineering of all SEW components connected to the MOVI-PLC
®
advanced DHE41B controller can
be carried out using the MOVI-PLC
®
advanced DHE41B controller.
Engineering of the MOVI-PLC
®
advanced DHE41B controller cannot be performed via the inverters.
•MOVITOOLS
®
MotionStudio PC software with PLC-Editor
MOVI-PLC
®
advanced DHE41B controller
P
i
f
kVA
Hz
n
