6-3
CHAPTER6
PART NAMES AND FUNCTIONS
Interior
GENERAL INFORMATION
Part names and functions
Fusing unit
The fusing unit is hot. Exercise care in this area.
Transport lever
Turn to open the transport section.
Photoconductive drum
Copy images are formed on the photoconductive
drum.
Corona unit
The unit is used to charge the photoconductive
drum.
Toner hopper
Contains toner.
Roller rotating knobs
Turn to remove misfed paper.
Paper guide
Push down to remove misfed paper.
Accessories
Operation manual . . . . . . . . . . . . . . . . . . . . . 1
Toner collecting containers
(including 1 pre-installed at the factory) . . . . . 3
To Next Page
