CHAPTER5

COPIER TROUBLE? Maintenance required

MAINTENANCE REQUIRED

When the message “READY TO COPY. (MAINTENANCE REQUIRED)”

appears in the message display, service by an authorised Sharp

Service Technician will be required soon. Contact your Service Centre

as soon as possible.
