Sharp AR-505 - Chapter 7 Optional Equipment

7-1
CHAPTER7
CHAPTER 7
OPTIONAL EQUIPMENT
This chapter describes operating instructions for the Finisher (AR-FN3),
Large Capacity Tray (AR-LC1N) and Stand/500-sheet Paper Drawer
(AR-DE7) .
Page
●●
●●
●
SYSTEM CONFIGURATION .......................... 7-2
●●
●●
●
FINISHER (AR-FN3)................................ 7-3
●
Part names ..................................... 7-3
●
Specifications ................................... 7-3
●
Offset stack ..................................... 7-4
●
Sort and group ................................... 7-5
●
Staple sort ...................................... 7-6
●
Staple cartridge replacement ....................... 7-10
●
Staple jam removal............................... 7-12
●
Misfeed removal................................. 7-14
●●
●●
●
LARGE CAPACITY TRAY (AR-LC1N) .................. 7-19
●
Part names .................................... 7-19
●
Specifications .................................. 7-19
●
Loading copy paper .............................. 7-20
●
Misfeed removal................................. 7-21
●●
●●
●
STAND/500-SHEET PAPER DRAWER (AR-DE7).......... 7-23
●
Part names .................................... 7-23
●
Specifications .................................. 7-23
●
Loading copy paper .............................. 7-24
●
Misfeed removal................................. 7-25
