MX-M260/M310/M260N/M310N SIMULATION 6 - 9
Operation/procedure
1. Select the load to be checked with the 10-key, and press the
[START] key.
The motor for 10sec, the solenoid ON for 500msec, OFF for 500msec.
(20 times)
When the [SYSTEM SETTINGS] is pressed, the operation is interrupted.
The lift-up motor operates only when the tray is opened.
The lift-up motor operates only when the tray is opened.
Operation/procedure
Select the load to be checked with the 10-key, and press the [START] key.
The selected load is operated for 10sec.
Operation/procedure
1. Select the load to be set with the 10-key.
2. Press the [START] key.
When selected without setup, the selected value is registered and
highlighted. When selected with previous setup, the previous setup is
canceled and it is displayed normally.
Press [CA] key, and the simulation will be terminated and the machine
goes into the aging standby mode with the set content.
This setting is canceled by power OFF.
*1: When the machine exits from the fusing ignoring state, the roller may
be cooled down. Therefore, reset the machine to warm up again.
When, therefore, the simulation is canceled by pressing the [CA]
key or when the copy mode display is shifted to the initial menu dis-
play in the simulation mode of one page copy, the machine is reset.
Note: In SIM 7-1, pressing [CA] key terminates the simulation and the
machine enters the aging mode without resetting. Therefore, to
perform “4. Intermittent setup,” the intermittent cycle must be set
with SIM 7-6 in advance.
Reset is not performed when the machine enters the aging mode.
Operation/procedure
1. Enter the interval aging cycle time (sec) with the 10-key pad.
Refer to SIM 7-1.
2. Press the [START] key.
When the [START] key is pressed in aging, copying is performed con-
tinuously. This simulation is used to set the time interval between copy
operations in the unit of second.
This setting is valid when SIM 7-1 (Intermittent setting) is enabled.
6
6-1
Purpose Operation test/check
Function
(Purpose)
Used to check the operation of the loads (clutches and
solenoids) in the paper transport system and the
control circuit.
Section Paper transport (Discharge/Switchback/Transport)
Item Operation
Item Content
1 LUM1 1st tray lift-up motor
2 CPFC1 1st tray pick-up solenoid
3 CPFS1 1st tray paper feed clutch
4 MPFS Manual feed pick-up solenoid
5 RRC Resist roller clutch
6 PSPS Separation pawl solenoid
7 OGS Paper exit gate switching solenoid
8 LUM2 2nd tray lift-up motor
9 CPFC2 2nd tray pick-up solenoid
10 CPFS2 2nd tray paper feed clutch
11 TRC2 2nd tray transport roller clutch
12 LUM3 3rd tray lift-up motor
13 CPFC3 3rd tray pick-up solenoid
14 CPFS3 3rd tray paper feed clutch
15 TRC3 3rd tray transport roller clutch
16 LUM4 4th tray lift-up motor
17 CPFC4 4th tray pick-up solenoid
18 CPFS4 4th tray paper feed clutch
19 ROGS Right paper exit gate solenoid
6-2
Purpose Operation test/check
Function
(Purpose)
Used to check the operation of each fan motor and its
control circuit.
Section Others
Item Operation
Item Content
1 VFM Fusing fan operates
2 DCFM&DCFM2
Power cooling fan, power cooling fan 2
operations
3 VFM2 Fusing exit paper fan operates
3
VFM&DCFM&DCFM2
&VFM2
Fusing fan, power cooling fan, and
power cooling fan 2 are operated at the
same time.
7
7-1
Purpose Setting/Operation test/check
Function (Purpose) Used to set the aging operation conditions.
Item Operation
Item Content
1 AGING Aging enable/disable setting
2 MISFEED Jam detection enable/disable setting
3 FUSING*1
Fusing operation enable/disable setting
The fusing temperature is not controlled.
The heater is not turned ON.
4 INTERVL Intermittent setting (Valid only when set to AGING.)
5WARMUP
Warm-up save setting
The machine goes into the ready state only by
shading, disregarding fusing and process control.
After going into the ready state, normal control is
performed.
6 DV CHK. Developing unit detection enable/disable setting
7-6
Purpose Setting/Operation test/check
Function (Purpose) Used to set the cycle of intermittent aging.
Item Operation
Setting range 1-255
Default 3
To Next Page
