Sharp MX-M260 Service Manual

MX-M260/M310/M260N/M310N SIMULATION 6 - 10
Operation/procedure
1. Warm-up starts by the cover open/close.
(Can be performed repeatedly by open/close of the cover.)
2. The warm-up time is counted up and displayed in the unit of sec.
If the [CA] key is pressed at this time, count-up is interrupted to ter-
minate the simulation. (However, warm-up is continued.)
3. After completion of warming up, “WARM UP COMPLETED” is dis-
played and the control returns to the initial screen.
Operation/procedure
1. Touch the exposure mode to be changed.
The current set value is displayed.
2. Enter the set value with the 10-key.
3. Press the [START] key.
Output is made with the entered value, and the display returns to the
original state.
(
∗) Linked with the destinations of SIM 26-6.
Linked with the auto exposure mode of SIM 46-19-1.
The minimum increment is 10V.
The result of (Set value) -200/ 10 is stored in the EEPROM.
When reading a value from the EEPROM, the value of (EEP value
*10+200) is used as the set value.
Operation/procedure
1. Touch the exposure mode to be changed.
The current set value is displayed.
2. Enter the set value with the 10-key.
3. Press the [START] key.
Output is made with the entered value for 30sec, and the display
returns to the original state.
Min. unit: 10V increment
(
∗) Linked with the destinations of SIM 26-6.
Linked with the auto exposure mode of SIM 46-19-1.
Operation/procedure
1. Touch the exposure mode to be changed.
The current set value is displayed.
2. Enter the set value with the 10-key.
3. Press the [START] key.
7-8
Purpose Setting/Operation test/check
Function
(Purpose)
Used to set the display of the warm-up time.
Item Operation
8
8-1
Purpose Adjustment/Operation test/check
Function
(Purpose)
Used to check and adjust the operation of the
developing bias voltage in each copy mode and the
control circuit.
Section
Image process
(Photoconductor/Developing/Transfer/Cleaning)
Developer/Toner hopper
Item Content
Setting
range
Default
1 AE (145) AE (145mm/s)
200-
650
450
2 TEXT (145) Character (145mm/s) 450
3 TEXT/PHOTO (145)
Character/Photo
(145mm/s)
450
4 PHOTO (145) Photo (145mm/s) 450
5 TONER SAVE (145) Toner save (145mm/s) 400
6 AE (122) AE (122mm/s) 450
7 TEXT (122) Character (122mm/s) 450
8 TEXT/PHOTO (122)
Character/Photo
(122mm/s)
450
9 PHOTO (122) Photo (122mm/s) 450
10 TONER SAVE (122) Toner save (122mm/s) 400
8-2
Purpose Adjustment/Operation test/check
Function
(Purpose)
Used to check and adjust the operation of the main
charger grid voltage in each copy mode and the control
circuit.
Section
Image process
(Photoconductor/Developing/Transfer/Cleaning)
Photo conductor
Item Content
Setting
range
Default
1 AE (145) AE (145mm/s)
350-
750
590
2 TEXT (145) Character (145mm/s) 590
3 TEXT/PHOTO (145)
Character/Photo
(145mm/s)
590
4 PHOTO (145) Photo (145mm/s) 590
5 TONER SAVE (145) Toner save (145mm/s) 540
6 AE (122) AE (122mm/s) 590
7 TEXT (122) Character (122mm/s) 590
8 TEXT/PHOTO (122)
Character/Photo
(122mm/s)
590
9 PHOTO (122) Photo (122mm/s) 590
10 TONER SAVE (122) Toner save (122mm/s) 540
8-10
Purpose Adjustment/Operation test/check
Function
(Purpose)
Used to check and adjust the operation of the
developing bias voltage in each printer mode and the
control circuit.
Section
Image process
(Photoconductor/Developing/Transfer/Cleaning)
Developer/Toner hopper

Sharp MX-M260 Specifications

General

Print Technology	Laser
Print Speed	26 ppm
Max Print Resolution	600 x 600 dpi
Copy Speed	26 cpm
Max Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Warm-up Time	25 seconds
Fax Resolution	200 x 200 dpi
Paper Capacity	1, 100 sheets
Max Paper Size	A3
Duplex Printing	Yes
Functions	Print, Copy, Scan
Zoom Range	25% to 400%
Supported Paper Sizes	A4, A5, B5
Network Connectivity	Optional (Ethernet)
USB Connectivity	USB 2.0
Weight	28.5 kg
