MX-M260/M310/M260N/M310N SIMULATION 6 - 11
Output is made with the entered value for 30sec, and the display
returns to the original state.
The minimum increment is 10V.
The result of (Set value) -200/ 10 is stored in the EEPROM.
When reading a value from the EEPROM, the value of (EEP value
*10+200) is used as the set value.
Operation/procedure
1. Touch the exposure mode to be changed.
The current set value is highlighted.
2. Enter the set value with the 10-key.
3. Press the [START] key.
Output is made with the entered value for 30sec, and the display
returns to the original state.
Min. unit: 10V increment
Operation/procedure
1. Enter the set value with the 10-key.
2. Press the [START] key.
Output is made with the entered value for 30sec. and the display
returns to the original state.
The minimum increment is 10V.
The result of (Set value-200) / 10 is stored in the EEPROM.
When reading a value from the EEPROM, the value of (EEP value ∗ 10
+200) is used as the set value.
Therefore, an even number must be entered. If not, the entered odd
number +1 is displayed after pressing [START] key.
Operation/procedure
1. Enter the set value with the 10-key.
2. Press the [START] key.
Output is made with the entered value for 30sec. and the display
returns to the original state.
Operation/procedure
1. Select the operation mode with the 10-key.
2. Press the [START] key.
The operation is performed for 30sec, and the display returns to the
original state.
Item Content
Installa
tion
range
Default
1 DENS1 (145) Density1 (145mm/s)
200-
650
300
2 DENS2 (145) Density2 (145mm/s) 370
3 DENS3 (145) Density3 (145mm/s) 420
4 DENS4 (145) Density4 (145mm/s) 530
5 DENS5 (145) Density5 (145mm/s) 600
6 TS (145) Toner save (145mm/s) 250
7 DENS1 (122) Density1 (122mm/s) 300
8 DENS2 (122) Density2 (122mm/s) 370
9 DENS3 (122) Density3 (122mm/s) 420
10 DENS4 (122) Density4 (122mm/s) 530
11 DENS5 (122) Density5 (122mm/s) 600
12 TS (122) Toner save (122mm/s) 250
8-11
Purpose Adjustment/Operation test/check
Function
(Purpose)
Used to check and adjust the operation of the main
charger grid voltage in each printer mode and the
control circuit.
Section
Image process
(Photoconductor/Developing/Transfer/Cleaning)
Photo conductor
Item Content
Installa
tion
range
Default
1 DENS1 (145) Density 1 (145mm/s)
350-
750
440
2 DENS2 (145) Density 2 (145mm/s) 510
3 DENS3 (145) Density 3 (145mm/s) 560
4 DENS4 (145) Density 4 (145mm/s) 670
5 DENS5 (145) Density 5 (145mm/s) 740
6 TS (145) Toner save (145mm/s) 390
7 DENS1 (122) Density 1 (122mm/s) 440
8 DENS2 (122) Density 2 (122mm/s) 510
9 DENS3 (122) Density 3 (122mm/s) 560
10 DENS4 (122) Density 4 (122mm/s) 670
11 DENS5 (122) Density 5 (122mm/s) 740
12 TS (122) Toner save (122mm/s) 390
8-13
Purpose Adjustment/Operation test/check
Function
(Purpose)
Used to check and adjust the operation of the
developing bias voltage in FAX mode and the control
circuit.
Section
Image process
(Photoconductor/Developing/Transfer/Cleaning)
Developer/Toner hopper
Setting range 200-650
Default 450
8-14
Purpose Adjustment/Operation test/check
Function
(Purpose)
Used to check and adjust the operation of the main
charger grid voltage in FAX mode and the control
circuit.
Section
Image process
(Photoconductor/Developing/Transfer/Cleaning)
Photo conductor
Setting range 350-750
Default 590
9
9-1
Purpose Operation test/check
Function
(Purpose)
Used to check and adjust the operation of the load
(motor) in the duplex section and the control circuit.
Section Duplex
Item Operation
Item Content
1 DMF145
Duplex motor/Duplex 2 motor forward rotation
(145mm/s)
2 DMF122
Duplex motor/Duplex 2 motor forward rotation
(122mm/s)
3 DMR145
Duplex motor/Duplex 2 motor reverse rotation
(145mm/s)
4 DMR122
Duplex motor/Duplex 2 motor reverse rotation
(122mm/s)
To Next Page
