122
KEY OPERATOR PROGRAMS
Key operator programs
P47 Stream Feeding Mode
Program P47 is used to enable the stream feeding mode of the
document feeder. When the stream feeding mode is enabled, additional
originals which are set in the document feeder tray within 5 seconds
after the previous original was fed will be fed and copied automatically.
When P47 is entered, the following message will appear.
P47: STREAM FEEDING MODE (DOCUMENT
FEEDER).
1.YES 2.NO
To enable the stream feeding mode, press key 1.
To disable the stream feeding mode, press key 2.
P50 Staple Position Setting
Program P50 is used to select the initial stapling position for an
optional 20-bin staple sorter (SF-S55N).
When P50 is entered, the following message will appear.
P50: STAPLE POSITION SETTING.
USE 10-KEY PAD TO SELECT.
CORNER TWO STAPLE ONE STAPLE
:PRESS 1 :PRESS 2 :PRESS 3
Select the desired stapling position using the 10-key pad.
A4R
A4
A3 B4 A3 B4
A4 A4R
