72
GENERAL
INFORMATION
SPECIFICATIONS
Specifications
COPIER
Type Console
Copy system Dry, electrostatic transfer system
Originals Sheets, bound documents
Original feed system Reversing automatic document feeder (RADF)
Original size Max. A3 (11" x 17")
Copy sizes Max. A3 (11" x 17"), min. A6 (5-1/2" x 8-1/2")
Image void: Max. 3 mm (1/8") (leading edge)
Max. 4 mm (5/32") (trailing edge)
Copying speed 52 copies/min. (A4, 8-1/2" x 11")
(at 100% copy ratio) 40 copies/min. (A4R (8-1/2" x 11"R))
33 copies/min. (B4 (8-1/2" x 14"))
29 copies/min. (A3 (11" x 17"))
Continuous copy Max. 999 copies; subtractive counter
First-copy time Approx. 2.7 sec.
Warm-up time Approx. 3 min.
Copy ratio Variable: 50 to 200% in 1% increments, total 151 steps
Fixed presets: 50%, 70%, 81%, 86%, 100%, 115%,
122%, 141%, 200% (50%, 64%, 77%, 95%, 100%,
121%, 129%, 141%, 200%)
Exposure system Moving optical source, slit exposure
(stationary platen) with automatic exposure
function
Copy paper feed Three paper trays with automatic feed (500 sheets each)
and one manual feed tray with 100-sheet automatic feed
capability
Fusing system Heat rollers
Developer system Magnetic brush development
Light source Halogen lamp
Required power supply Local voltage ±10% (For this copier’s power supply
requirements, see the name plate located on the right
hand side, near the rear of the copier.)
Power consumption Max. 1.8 kW (when an optional sorter or staple sorter is
installed)
Overall dimensions 1407 mm (W) x 660 mm (D)
(55-13/32" (W) x 25-63/64" (D))
Weight Approx. 141.5 kg (312 lbs.)
