Sharp SF-2052 - Interior

67
GENERAL INFORMATION
!7 Paper tray 1
Holds 500 sheets of copy paper.
!8 Paper tray 2
Holds 500 sheets of copy paper.
!9 Paper tray 3
Holds 500 sheets of copy paper.
@0 Fusing unit
The fusing area is hot. Exercise care in this area.
@1 Transport lever
Turn to open the transport section.
@2 Photoconductive drum
Copy images are formed on the drum.
@3 Roller rotating knobs
Turn as indicated to remove misfed paper.
@4 Duplex section
Duplex copies are inverted here.
@5 Toner collecting container
Used toner is collected here.
(Replacement of toner collecting container
should only be done by an authorised Sharp
service technician.)
Accessories
Operation manual........................................ 1
Corona cleaner............................................ 1
PART LOCATIONS AND FUNCTIONS
Interior
@1@0 @2
@
3
@
4
@
5
Part locations and functions
