97
(3) Assembly
Reassembly generally follows the disassembly procedure
in reverse.
Be sure all components are free of dirt and foreign matter
and lubricate all components with clean hydraulic oil on
assembly.
During assembly observe the followings:
1. Remove the oil stained from the bolts ①, thread and
thread holes of clutch shaft ②, with the solvent, and
then apply the thread sealant to threads when install
the clutch fork ③.
2. Position the lever ①, of clutch shaft as shown figure
before install the PTO clutch assembly.
337X
338X
