Shinko BCS2R Series User Manual

18
8. Specifications
8.1 Standard specifications
Mounting: Flush
Setting: Input system using membrane sheet key
Display: PV Display: Red LED 4 digits, character size 12.4 x 5.8 mm (H x W)
SV Display: Green LED 4 digits, character size 8.8 x 3.9 mm (H x W)
Accuracy (Setting and Indication):
Thermocouple: Within 0.2% of each input span 1digit, or within 2 (4 ),
whichever is greater
However R, S inputs, 0 to 200 (32 to 392 ): Within 6 (12 )
B input, 0 to 300 (0 to 572 ): Accuracy is not guaranteed.
K, J, E, T, N inputs, less than 0 (32 ): Within 0.4% of input span 1digit
RTD: Within 0.1% of each input span 1digit, or
within 1 (2 ), whichever is greater
Direct current: Within 0.2% of each input span 1digit
DC voltage: Within 0.2% of each input span 1digit
Input sampling period: 0.25 seconds
Input: Thermocouple: K, J, R, S, B, E, T, N, PL- , C(W/Re5-26) External resistance: 100 or less
(However, B input: External resistance: 40 or less)
RTD: Pt100, JPt100, 3-wire type
Allowable input lead wire resistance (10 or less per wire)
Direct current: 0 to 20 mA DC, 4 to 20 mA DC
Input impedance (50 )
Built-in shunt resistor (50 )
Allowable input current, 50 mA or less
DC voltage: 0 to 1 V DC
Input impedance (1 M or more)
Allowable input voltage (5 V or less)
Allowable signal source resistance (2 k or less)
0 to 5 V DC, 1 to 5 V DC, 0 to 10 V DC
Input impedance (100k or more)
Allowable input voltage (15V or less)
Allowable signal source resistance (100 or less)
OUT1 (Limit control output)
Relay contact: 1a, Control capacity 3A 250 V AC (resistive load)
1A 250 V AC (inductive load cos =0.4)
Electrical life: 100,000 cycles
Minimum applicable load: 10 mA 5 V DC
A1 output
Action: ON/OFF action
Hysteresis: 0.1 to 100.0 ( ), or 1 to 1000 (DC input) (Default: 1.0 )
Output: Relay contact 1a
Control capacity, 3 A 250 V AC (resistive load)
1 A 250 V AC (inductive load cos =0.4)
Electrical life: 100,000 cycles
Minimum applicable load: 10 mA 5 V DC
Control action
High limit control action, Low limit control action
OUT1 (Limit control output) hysteresis: 0.1 to 100.0 ( ), or 1 to 1000 (DC input)
