Frequency Response
1 Hz 20 kHz (+0.5 dB/3 dB
Audio Injected at Dante Input
Total Harmonic Distortion
0.01%, typical
Audio Injected at Dante Input
Dynamic Range
100 dB (Aweighted), 97 dB (Unweighted), typical
Audio Injected at Dante Input
Load Impedance
>600 Ω, typical
Type
3-pin male XLR
Pin Assignments
Standard XLR Pinout
1=ground, 2=audio +, 3=audio −
GND Lift
Left Pin 1=GND Connected
Right Pin 1=GND Disconnected
RF
WLAN Standard
IEEE 802.11 a, g
Frequency Bands
2.4 GHz ISM, 5 GHz UNII
Sensitivity
80 dBm at 10% PER
Output Power
1 mW (Low), 5 mW (Medium), 13 mW (High), 25 mW (Maximum )
Antenna Type
Proprietary Internal Bi-level Dual-band (PIFA), patent pending
