Automatic Group Setup
An MXW Group can be associated without use of the control software when a network is comprised of only one Access Point Transceiver (APT), one
Networked Charging Station (NCS) and one Audio Network Interface (ANI). For best results, perform a factory default on the devices to clear any previous
Group associations.
1. Connect one APT, one NCS and one ANI to the network. The network must only contain one of each device.
2. Perform a factory reset on the devices (see the Factory Default section).
3. On the front panel of the ANI, press both input level selection buttons at the same time and hold for five seconds. The Channel Select LEDs will illuminate
green and the audio meter will flash to indicate that the association is successful.
Channel Mapping for Devices in a Group
Audio is routed from the microphones to the analog outputs according to the Group setup in the Configuration tab. The following diagram displays
channel mapping for devices in eight- and four-channel Groups.
Networked Charging Station
An additional charging station is required when filling a
Group with gooseneck microphones
8-Channel Group 4-Channel Group
Audio Output Device
Outputs are assigned to an MXW Audio Network
Interface or SCM820 Automatic Mixer
8-Channel Group 4-Channel Group
A B A B A B A B
2 3 4
5 6 7 8
1
2 3 41
x x x x
81 2 3 4 5 6 7
1 2 3 4
(none) (none) (none)(none)
1) 1) 1) 1)
2 3 41
x x x x
2
3
4
1
5 6 7 8
x
x x x
1 2 3 4
85 6 7
1 2 3 4 x x x x
(none)(none)
2) 2) 2) 2)
5 6
7 8
2 3 41
x x x x
21
x x
3 4
x x
3) 3)
5 6
7 8
2
3 4
1
4)
