Microflex Wireless Specifications
Audio Frequency Response
20 Hz to 20 kHz (+1, −1.5 dB)
Dynamic Range
20 Hz to 20 kHz, A-weighted, typical
Analog-to-Dante 113 dB
Dante-to-Analog 110 dB
Output Noise
20 Hz to 20 kHz, A-Weighted, typical
Line Aux Mic
−84.5 dBV −95.2 dBV −106.5 dBV
THD+N
20 Hz to 20 kHz+4dBu analog input, −10 dBFS digital
input
<0.05%
Polarity
Non-inverting, any input to any output
Dimensions
44 mm x 483 mm x 366 mm (1.7 in. x 19.0 in. x
14.4 in.), H x W x D
Weight
MXWANI4 3.1 kg (6.9 lbs)
MXWANI8 3.2 kg (7.1 lbs)
Housing
Steel; Extruded aluminum
Power Requirements
100 to 240 V AC, 50-60 Hz, 1 A
Operating Temperature Range
−18°C (0°F) to 63°C (145°F)
Storage Temperature Range
−29°C (-20°F) to 74°C (165°F)
Audio Network Interface (ANI)
Analog Connections
Outputs
Configuration Impedance Clipping Level (minimum)
Line Aux Mic
Active Balanced 310 Ω +26.2 dBV +16.2 dBV −3.8 dBV
Input(s)
Configuration Impedance Clipping Level (minimum)
Line Aux
Active Balanced 10.6 kΩ +23.8 dBV +10.8 dBV
Headphone Output
6.35 mm (1/4") TRS, 100 mW, 350 Ω, dual mono (will drive stereo phones)
Digital Signal Processing
AD/DA Converter
24-bit, 48 kHz
Latency
Estimated Nominal, ±0.1 ms
Analog-to-Dante 0.21 ms
Dante-to-Analog 0.24 ms + TN
TN = Network latency in milliseconds, as set in Dante Controller.
Note: Dante network latency is typically associated with the receiving device.
Networking
Network Interface
Four-Port Gigabit Ethernet Switch, Dante digital audio
Uplink Port (Port 4)
Selectable, blocks multicast traffic
Power over Ethernet (PoE)
Provided on Port 1 to power MXWAPT
Cable Requirements
Cat 5e or higher, shielded, 100 m maximum between network devices
Network Addressing Capability
DHCP, link-local, static
Access Point Transceiver (APT)
Network Interface
RJ45: Gigabit Ethernet, Dante digital audio
Plenum Rating
UL 2043
Power Requirement
Power over Ethernet (PoE) Class 0, 6.5W
Antenna Type
Internal, Spatial Diversity, Circular Polarization
Housing
Molded Plastic, Cast Zinc
Dimensions
24 mm x 170 mm x 170 mm (1.35 in. x 6.7 in. x 6.7 in.), H x W x D
Without mounting plate or cover
Weight
APT8 856 g (1.9 lbs)
APT4 845 g (1.9 lbs)
Paintable Cover 85 g (0.2 lbs)
Mounting Bracket 68 g (0.15 lbs)
0 dBV=1 V RMS
0 dBu=0.775 V RMS
0 dBV=2.2 dBu
