55
Microflex Wireless Specifications
RF Carrier Frequency Range
USA, Canada, Mexico 1920–1930 MHz
Europe, Asia, Middle-East 1880–1900 MHz
Working Range
50 m (160 ft)
Note: Actual range depends on RF power setting, signal absorption, reflection, and
interference.
Audio Frequency Response
50 Hz – 20 kHz (+1, -3 dB)
Note: Dependent on microphone type
Dynamic Range
>99 dB, A-weighted
System Gain
Mic gain @ 0dB to line level output on MXWANI through Dante
+50 dB
Latency
18 ms, nominal
MXW System
MXW Transmitters
MXW1 Hybrid Bodypack
Transmitter
Microphone Connector
4-Pin male mini connector (TA4M), See
drawing for details
Input Impedance
@ 1 kHz
>20 kΩ
Internal Microphone
Omnidirectional (20 Hz– 20 kHz)
Dimensions
22 mm x 45 mm x 99 mm (0.9 in. x 1.8 in. x
3.9 in.) H x W x D
Weight
85 g (3.0 oz.)
with batteries, without microphone
MXW6 Boundary
Transmitter
Microphone Capsule
MXW6/O R183B
MXW6/C R185B
Dimensions
23 mm x 44 mm x 114 mm (0.9 in. x 1.75 in.
x 4.5 in.) H x W x D
Weight
108 g (3.8 oz.)
with batteries
Microflex Wireless Specifications
System Audio Polarity
Positive pressure on microphone diaphragm (or positive voltage on pin 3
of TA4M connector) produces a positive voltage on pin 2 of the ANI (with
respect to pin 3 of the low-impedance output).
Radio Transmission
Time Division Multiple Access (TDMA), Gaussian Frequency Shift Keying
(GFSK), 365 kHz max. deviation
RF Sensitivity
−87 dBm, minimum
Power
19 dBm (80 mW) maximum, See Frequency Range and Output Power table
Cable Requirements
Cat 5e or higher, shielded, 100 m maximum between network devices
Network Addressing Capability
DHCP, link-local, static
Operating Temperature Range
0°C (32°F) to 49°C (120°F)
Storage Temperature Range
-29°C (-20°F) to 74°C (165°F)
Gain Adjustment Range
−25 to +15 dB (in 1 dB steps)
Maximum Input Level
Mic gain @ −16 dB
−9 dBV
Headphone Output
3.5 mm (1/8"), dual mono (will drive stereo
phones)
Maximum Headphone Output Power
1kHz @ 1% distortion, peak power, @16Ω
17.5 mW
Antenna Type
Internal, Spatial Diversity, Linear Polarization
Battery Type
Rechargeable Li-Ion
Battery Life
MXW1, MXW6, MXW8 Up to 9 hours
MXW2 Up to 15 hours
Calculated with a new battery. Runtimes vary depending
on battery health.
Charge Connector
USB 3.0 Type A
Housing
Molded Plastic
Recommended Storage Temperature Range
0°C (32°F) to 25°C (77°F)
MXW2 Handheld Transmitter
Microphone Capsule
SM58, SM86, Beta58, VP68
Configuration
Unbalanced
Input Impedance
@ 1 kHz
>20 kΩ
Dimensions
226 mm x 51 mm (8.9 in. x 2.0 in.) L x Dia.
including SM58 microphone capsule
Weight
323 g (11.4 oz.)
with batteries, including SM58 microphone capsule
MXW8 Gooseneck-Base
Transmitter
Microphone Connector
6-pin connector for Shure MX405/10/15
Configuration
Unbalanced
Input Impedance
@ 1 kHz
>20 kΩ
Gooseneck Options
See accessories list
Dimensions
36 mm x 71 mm x 124 mm (1.4 in. x 2.8 in. x
4.9 in.) H x W x D
Weight
193 g (6.8 oz.)
with batteries, without microphone
