656 229 2010-11-22| Sicam snc società unipersonale
28 | SBM 855 | User informationen
2. User information
2.1 Important notes
Important information on copyright, liability and warran-
ty provisions, as well as on equipment users and com-
pany obligations, can be found in the separate manual
"Important notes on and safety instructions for Sicam
Tire Service Equipment". These instructions must be
carefully studied prior to start-up, connection and opera-
tion of the SBM 855 and must always be heeded.
2.2 Safety instructions
All the pertinent safety instructions can be found in the
separate manual "Important notes on and safety instruc-
tions for Sicam Tire Service Equipment". These instruc-
tions must be carefully studied prior to start-up, connec-
tion and operation of the SBM 855 and must always be
heeded.
2.3 Electromagnetic compatibility (EMC)
The SBM 855 satisfies the requirements of the EMC
directive 2004/108/EG.
i The SBM 855 is a class/category A product as
defined by EN 61 326. The SBM 855 may cause
high-frequency household interference (radio inter-
ference) so that interference suppression may be
necessary. In such cases the user may be required to
take the appropriate action.
3. Product description
3.1 Intended use
The SBM 855 is a wheel balancing machine with me-
chanical attachment for the balancing of passenger
vehicle and commercial vehicle wheels (trucks, buses
and tractors) with a rim diameter of 10" – 30", a rim
width of 1" – 20" and a maximum weight of 160 kg. The
SBM 855 is to be used exclusively for this purpose and
solely for the range of applications specifi ed in these
instructions. Any other purpose is not consistent with
the intended use and is therefore not permissible.
i The manufacturer cannot accept any liability for pos-
sible damage arising from improper use.
3.2 Prerequisites
The SBM 855 must be installed on a flat surface
made of concrete or similar material and anchored in
position.
i An uneven or vibrating surface can lead to inaccurate
unbalance measurements.
3.3 Scope of delivery
Designation Order number
SBM 855 Refer to rating
plate
Quick-action clamping nut 616 200
Centering flange 653 249
Spacer ring for commercial vehicle flange 652 902
Commercial vehicle flange 652 901
Centering cones (3x) and adapters –
Manual vernier caliper 629 400
Weight pliers1 695 629 400 606 500
Measuring compasses1 695 629 400 652 870
Calibrating weight 654 377
Clamping nut 626 700
Wheel spider 626 800
Wheel lift 900 004
3.4 Special accessories
Designation Order number
Set of quick-action clamping cones M10x1.25
612 100
Third centering cone dia. 89 to 132 mm 653 449
Fourth centering cone dia. 120 to 174 mm 606 300
Spacer ring for rims (large rim offset) 606 200
Three-arm flange for light commercial
vehicles
653 420
Infinitely variable universal flange for cars
(3-4-5 hole)
654 043
Calibration weight (calibrated) 654 376
