Inductive load at nominal voltage
@ 100 mA
1,000 mH
1)
Max. –30 V DC, to avoid damaging the output.
Ma
x. –50 V DC, for fast switch-off of inductive loads.
2)
The output current is actively limited.
Test outputs (X) used as non-safe outputs
T
able 144: Technical data when using test outputs (X) as non-safe outputs (PNP or NPN)
Type of output Push-pull semiconductor, short-circuit protected
Output voltage High U
B
–3 V DC … U
B
Max. output voltage Low
1)
–50 V DC … –30 V DC
Maximum output current when used
a
s a PNP output
100 mA
Maximum output current when used
as a NPN output
–15 mA
Leakage current Low ≤ 0.1 mA
Inductive load at nominal voltage
2)
@ 100 mA
1,000 mH
Load capacity 1,000 µF
1)
Max. –30 V DC, to avoid damaging the output.
Ma
x. –50 V DC, for fast switch-off of inductive loads.
2)
Only permissible if used as a PNP output.
Safety outputs (Q)
T
able 145: Technical data for the safety outputs (Q)
Type of output PNP semiconductor, short-circuit protected
Output voltage High U
B
–3 V DC … U
B
Max. output voltage Low
1)
–50 V DC … –30 V DC
Maximum reverse voltage at Low
2)
3 V DC
Leakage current Low
Normal operation < 1 mA
Dual channel < 2 mA
Fault
3)
< 1 mA
Output current Max. 2 A
Sum current I
sum
T
U
≤
55 °C 4 A
Test pulse duration
4)
< 650 µs or deactivated
Test pulse frequency ≥ 190 ms
Cross-circuit detection using test pulses
5)
Cable resistance Max. 2.5 Ω (z. B. 100 m × 1.5 mm² = 1.2 Ω)
Output current, dual-channel out‐
put
s
Max. 1 A per output
Load capacity ≤ 0.5 µF
Load capacity when connected via
diode
≤ 1,000 µF
Inductive load at nominal voltage
@2 A 100 mH
@1 A 1.6 H
13 TECHNICAL DATA
130
O P E R A T I N G I N S T R U C T I O N S | Flexi Compact 8024589/2020-11-10 | SICK
Subject to change without notice
