Address Contents Data type Size
3060 Description STRING 50 words (100 bytes)
1)
The first 32 bytes contain the module statuses of the CPU. This is followed by 8 byes each for the module
s
tatuses of the expansion modules. The order depends on the hardware configuration. The content
depends on the type of expansion module.
Description of the device status
T
able 162: Device status
Value Device status Description
0 Unknown State No supply voltage
1 Start-up Self-test is in progress or the safety controller is being
init
ializing.
2 Service Mode Configuration is being transferred to the device. Configu‐
ration data are being saved in the SmartPlug.
3 Normal Operation Application is running.
4 Suspended Operation Application is ready to run.
6 Service Required
•
Smar
tPlug not inserted or incompatible with this
module.
•
Configuration is invalid.
7 Recoverable Error Application is running.
A r
ecoverable external error is present at this module.
8 Fatal error The application was stopped. All outputs of the safety
cont
roller are switched off.
Description of the required user actions
T
able 163: Required user action
Bit Required user action
0x00 01 Confirm configuration
0x00 02 Check configuration
0x00 08 Check application interface
0x00 10 Checking the device
0x00 20 Perform set-up procedure
0x00 40 Checking the firmware
0x00 80 Waiting
Description of the product codes
Pr
oduct codes are 4-byte coded device type codes.
Table 164: Product codes
Product codes Description
0x30 01 00 00 CPUc1 main module
0x31 01 00 00 CPUc2 main module
0x00 05 00 00 EtherCAT gateway expansion module
0x00 06 00 00 PROFINET gateway expansion module
0x30 0B 00 00 XTDI IO expansion module
0x30 0C 00 00 XTDO IO expansion module
0x30 FF 00 00 SmartPlug
13 TECHNICAL DATA
140
O P E R A T I N G I N S T R U C T I O N S | Flexi Compact 8024589/2020-11-10 | SICK
Subject to change without notice
