Address Contents Data type Size Description
(20) Product name STRING 16 words
(32 b
ytes)
Product name, e.g., Flexi
Compact CPUc2
(36) Model name STRING 9 words
(18 bytes)
Type code
(45) Serial number STRING 4 words
(8 bytes)
Serial number of the mod‐
ule
(49) Application name STRING 16 words
(32 bytes)
Application name entered
in the configuration soft‐
ware
(65) Modbus® TCP profile
v
ersion
STRING 6 words
(12 bytes)
Version, e.g., 1.0.0
13.3.1.1.2 Result
Table 160: Modbus® TCP – Input data
Address Contents Size Description
256 Input values 1 word (2 bytes) Is determined by the con‐
f
iguration in the configura‐
tion software.
… 1 word (2 bytes)
280 1 word (2 bytes)
13.3.1.1.3 Status
Table 161: Modbus® TCP – Checksums, status information and metadata
Address Contents Data type Size
2000 Device status
see
table 162, page 140
USINT 1 word (2 bytes, MSB
always 0)
2001 Required user action
see
table 163, page 140
UINT 1 word (2 bytes)
2002 Overall checksum value UDINT 2 words (4 bytes)
2004 Safety checksum UDINT 2 words (4 bytes)
2005 Standard checksum UDINT 2 words (4 bytes)
2006 Reserved UDINT 2 words (4 bytes)
2007 Verification checksum UDINT 2 words (4 bytes)
2020 Product codes
1 x CP
U
1 x SmartPlug
16 x expansion modules
see table 164, page 140
UDINT 36 words (72 bytes)
2300
1)
Module status
4 x CP
U status info
see table 165, page 141
16 x module status info
see table 166, page 141
see table 167, page 142
see table 168, page 142
BYTE 80 words (160 bytes)
3000 Project name STRING 32 words (64 bytes)
3016 Device name STRING 32 words (64 bytes)
3032 Application name STRING 32 words (64 bytes)
3048 User name STRING 32 words (64 bytes)
TECHNICAL DATA 13
8024589/2020-11-10 | SICK O P E R A T I N G I N S T R U C T I O N S | Flexi Compact
139
Subject to change without notice
