13.3.2.1.2 Checksums
Table 172: Checksums
Address Contents Data type Size
150 most significant word
151 le
ast significant word
Overall checksum value CRC32 2 words (4 bytes)
152 most significant word
153 le
ast significant word
Safety checksum CRC32 2 words (4 bytes)
154 most significant word
155 le
ast significant word
Standard checksum CRC32 2 words (4 bytes)
156 most significant word
157 le
ast significant word
Reserved CRC32 2 words (4 bytes)
158 most significant word
159 le
ast significant word
Verification checksum CRC32 2 words (4 bytes)
13.3.2.1.3 Product codes
Table 173: Product codes
Address Contents Data type Size
200 Product codes
1)
:
•
Pr
oduct code of the CPU (4 bytes)
•
Product code of the SmartPlug
(4 bytes)
•
Product codes of the expansion
modules (4 bytes each)
UINT32 100 words
(200 bytes)
1)
Unavailable data are padded with “0”.
13.3.2.1.4 Status
Table 174: Status
Address Contents Size
350 SystemStatusInfo
1)
208 words (416 bytes)
1)
Unavailable data are padded with “0xFF”.
13.3.2.1.5 Device
Table 175: Device
Address Contents Data type Size
714 Vendor name ASCII
S
TRING
4 words (8 bytes)
718 Product code ASCII
S
TRING
4 words (8 bytes)
722 Product name ASCII
S
TRING
16 words (32 bytes)
738 Model name ASCII
S
TRING
9 words (18 bytes)
747 Revision ASCII
S
TRING
6 words (12 bytes)
753 Serial number ASCII
S
TRING
12 words (24 bytes)
765 Application name ASCII
S
TRING
16 words (32 bytes)
13 TECHNICAL DATA
144
O P E R A T I N G I N S T R U C T I O N S | Flexi Compact 8024589/2020-11-10 | SICK
Subject to change without notice
