8027872/1JTM/0-8/2023-05| SICK O P E R A T I N G I N S T R U C TI O N S | FLOWSIC550
Subject to change without notice
PROJECT PLANNING 5
5 Project planning
5.1 Preparing the measuring point
▸ Select a suitable installation location.
▸ Ensure adequate assembly clearances.
5.2 Choosing flanges, gaskets and other components
Mounting material will be provided by SICK.
Table 2: Mounting material
NOTICE:
For flange connections only use pipeline flanges, bolts, nuts and gaskets suitable for the
maximum operating pressure, maximum operating temperature as well as ambient and
operating conditions (external and internal corrosion).
Part No. Description
2130423
Mounting set for FLOWSIC550 meter installation 2'' with flange type
ANSI300/ANSI600
2130428
Mounting set for FLOWSIC550 meter installation 3'' with flange type
ANSI300/ANSI600
2075562
Adapter for connecting the EDT96 pressure sensor,
NPT 1/4“ - G 1/4“, stainless steel
