SICK PLOC2D 4.1 - Page 18

InspectorP631 C-mount
Working distance/focal position in mm
Field of view in mm²
0
0 200 400 600 800 1000 1200 1400 1600 1800 2000 2200
200 x 160
400 x 320
600 x 480
800 x 640
1000 x 800
1200 x 960
a
b
c
e
f
d
Field of view in mm²
400 x 320
100 x 80
200 x 160
300 x 240
0
0 200 400
Working distance/focal position in mm
600100 300 500
a: f = 8.0mm (only C-mount standard)
b: f = 12.0mm
c: f = 16.0mm
d: f = 25.0mm
e: f = 35.0mm
f: f = 50.0mm
a
b
c
e
f
d
1
1
2
2
3
3
1
Lens focal length
2
Working distance in mm
3
Field of view in mm
2
3 PRODUCT DESCRIPTION
18
O P E R A T I N G I N S T R U C T I O N S | PLOC2D 4.1 8020736/1K3Z/2023-06 | SICK
Subject to change without notice
