SICK PLOC2D 4.1 - Page 19

InspectorP631 S-mount
Field of view in mm²
0
0 200 400 600 800 1000 1200 1400 1600 1800 2000
a
b
c
d
200 x 160
400 x 320
600 x 480
800 x 640
1000 x 800
1200 x 960
Field of view in mm²
Working distance/focal position in mm
0 200 400 600100 300 500
100 x 80
400 x 320
200 x 160
300 x 240
0
a: f = 9.6mm
b: f = 12.5mm
c: f = 17.5mm
d: f = 25.0mm
Optional distance ring required
Working distance/focal position in mm
a
b
c
d
1
1
2
2
3
3
1
Lens focal length
2
Working distance in mm
3
Field of view in mm
2
PRODUCT DESCRIPTION 3
8020736/1K3Z/2023-06 | SICK O P E R A T I N G I N S T R U C T I O N S | PLOC2D 4.1
19
Subject to change without notice
