SICK TriSpector1060

1
Connector Encoder (thread inside)
2
Connector Gigabit Ethernet (Gig E)
3
Connector Power I/O (thread outside)
4
LED: On
5
LED: State
6
LED: Link/Data
7
LED: Result
8
LED: Laser
9
Fastening threads (M5x8.5 length)
ß
Optical receiver (center)
à
Optical sender (center)
á
SD-card
3.5.3 TriSpector1060
61.9 (1.26)
27.9
(1.10)
205.5 (8.09)
307 (12.09)
316.9 (12.48)
2
(0.08)
34
(1.34)
18.5
(0.73)
45
(1.77)
7.4
(0.29)
47
(1.85)
94 (3.70)
106.5
(4.19)
9.9
(0.39)
5.6
(0.22)
24 (0.94)
24 (0.94)
18
(0.71)
82 (3.23)
83.3 (3.28)
á ß à
1
2
4 5 6 7 8
3
9
M12 x 1
M12 x 1
M12 x 1
1
Connector Encoder (thread inside)
2
Connector Gigabit Ethernet (Gig E)
3
Connector Power I/O (thread outside)
4
LED: On
5
LED: State
6
LED: Link/Data
7
LED: Result
8
LED: Laser
9
Fastening threads (M5x8.5 length)
ß
Optical receiver (center)
à
Optical sender (center)
á
SD-card
3.6 LED indicators
Name Color Function
On Green Power on
State Green Ready for trig input and image acquisition
Link/Data Green Gigabit Ethernet (Gig E)
Link: LED on
Activity: LED blink
PRODUCT DESCRIPTION 3
8021808/12ID/2019-01 | SICK O P E R A T I N G I N S T R U C T I O N S | TriSpector1000
13
Subject to change without notice
