SICK TriSpector1060

Result Output
Area Area in mm
2
.
7.6.12 Distance tool
Distance The Distance tool measures the distance between two tool
key points.
Distance tool settings
Setting Description
Feature A First referenced feature for measuring dis‐
tance.
Feature B Second referenced feature for measuring dis‐
tance.
Measure type Use right angle or point-to-point measuring.
■
Right Angle projects a point feature onto a
line feature, and measures the distance
between the projected point and the line
feature.
■
Point To Point measures the distance
between point features.
Measure distance in Select dimensions to measure distance in.
Distance tool result output
Result Output
Decision OK/Not OK/Invalid/Neutral/Not found
Distance Distance in mm.
Select the Distance checkbox to use the dis‐
tance as a Pass/Fail condition.
GUI operations
Use the Switch features button ( ) to switch Feature A and Feature B.
Use the Select features button ( ) to enable or disable selection of features in the
image area.
7.6.13 Angle tool
Angle The Angle tool measures the angle between two planes.
Angle tool settings
Setting Description
Feature A First referenced plane tool for measuring
angle.
Feature B Second referenced plane tool for measuring
angle
7 OPERATION
40
