Attribute Value
Digital in-/ outputs 4 x, non-isolated, configurable
Encoder interface RS-422/TTL (DBS36E-BBCP02048)
Maximum encoder frequency 300 kHz
Fieldbuses Ethernet/IP via Gigabit Ethernet port
ProfiNet via serial interface connected to SICK
module CDF600-2200
10.4 Mechanics and electronics
Attribute Value
Power I/O M12 male connector, 12-pin A-coded
Gigabit Ethernet M12 female connector, 8-pin X-coded
Encoder M12 female connector, 8-pin A-coded
Connector material Brass, nickel-plated
Supply voltage 24 V DC, ± 20 %
SELV + LPS according to EN 60950-
1:2014-08 or Class 2 according to
UL1310 (6th edition)
Supply current 1.5 A maximum; external fuse required
Power consumption 11 W maximum
Ripple < 5 Vpp
Current consumption 400 mA with no output loads
Enclosure rating IP 67
Safety EN 60950-1:2014-08
Protection class III
EMC Immunity: EN 61000-6-2:2005
Emission: EN 61000-6-3:2007
Weight (not including cables) 1008: 900 g
1030: 1300 g
1060: 1700 g
Dimensions (L x W x H) 1008: 136 mm x 62 mm x 84 mm
1030: 217 mm x 62 mm x 84 mm
1060: 307 mm x 62 mm x 84 mm
Optics Fixed
10.5 Input switching levels
Attribute Value
Input levels Up to 30 V
Stresses beyond this over-voltage level can
cause permanent damage to the device.
Input threshold levels High: > 15.0 V
Low: < 5.0 V
Hysteresis > 1.0 V
Input current High: < 3.0 mA
Low: < 0.1 mA
10 TECHNICAL DATA
