11.3 Gráficos do ponto de luz
0
Distance in mm (inch)
Dimensions in mm (inch)
4
(0.16)
6
(0.24)
–6
(–0.24)
–4
(–0.16)
0
2
(0.08)
–2
(–0.08)
Recommended sensing range for
the best performance
150
(5.91)
100
(3.94)
50
(1.97)
200
(7.87)
250
(9.84)
300
(11.81)
10
(0.39)
250
(9.84)
110
(4.33)
Figura 17: WTB4SP-xxxxx1xx
0
Distance in mm (inch)
Dimensions in mm (inch)
4
(0.16)
6
(0.24)
–6
(–0.24)
–4
(–0.16)
0
2
(0.08)
–2
(–0.08)
Recommended sensing range for
the best performance
100
(3.94)
50
(1.97)
150
(5.91)
10
(0.39)
130
(5.12)
70
(2.76)
Figura 18: WTB4SP-xxxxx2xx
0
Distance in mm (inch)
Dimensions in mm (inch)
0
10
(0.39)
–10
(–0.39)
Recommended sensing range for
the best performance
20
(0.79)
–20
(–0.79)
100
(3.94)
50
(1.97)
150
(5.91)
10
(0.39)
150
(5.91)
50
(1.97)
Figura 19: WTB4ST-xxxxxAxx, tamanho do ponto de luz horizontal
