WTB4SP-xxxxx2xxxx:
0
150
(5.91)
100
(3.94)
50
(1.97)
0
y
x
y
x
Minimum distance in mm (y) between the set sensing
range and white background (90 % remission factor)
Example:
Safe suppression of the background
White background (90 %)
Black object (6 % remission factor)
Set sensing range x = 80 mm
Needed minimum distance to white
background y = 0.5 mm
Distance in mm (inch)
Recommended sensing range for
the best performance
5
(0.20)
4
(0.16)
3
(0.12)
2
(0.08)
1
(0.04)
2
6%/90%
1
1%/90%
90%/90%
4
3
18%/90%
Figure 6: WTB4SP-xxxxx2xxxx
4
2
3
1
0
Distance in mm (inch)
150
(5.91)
100
(3.94)
50
(1.97)
1304/10
904/10
4/10
4/10
130
130
D
C
A B
BluePilot
E
F
Recommended sensing range for
the best performance
Figure 7: WTB4SP-xxxxx2xxxx
1
ultra-black object, 1% remission factor
2
Black object, 6% remission factor
3
Gray object, 18% remission factor
4
White object, 90% remission factor
A Sensing range min. in mm
B Sensing range max. in mm
C Visibility range
D Setting range switching threshold for background suppression
E Sensing range indicator
F Teach-Turn adjustment
Blue Recommended sensing range for the best performance
