SICK WTB4S - Page 51

MultiMode 2
11.4 Process data structure
WTB4S A00
IO-Link V1.1
Process data 2bytes
Byte 0: Bits 15 ... 8
Byte 1: Bits 7 ... 0
Bit 0/data type Q
L1
/Boolean
Bit 1/data type Q
L2
/Boolean
Bit 2 ... 15/description/data type Current Receiver Level [digits]
12 Annex
12.1 Conformities and certificates
You can obtain declarations of conformity, certificates, and the current operating
instructions for the product at www.sick.com. To do so, enter the product part number
in the search field (part number: see the entry in the “P/N” or “Ident. no.” field on the
type label).
OPERATING INSTRUCTIONS
8028211/2023/10/20 | SICK O P E R A T I N G I N S T R U C T I O N S | WTB4S
51
Subject to change without notice
en
