3 Setting up functions 03/2013
3.4 Fault services
© Siemens AG 2006-2013 All Rights Reserved
3-132 SINUMERIK Integrate AMB, AMC, AMM, Function Manual (FH) - 03/2013
Function Description Type
Force absolute
address
To make it necessary for the trigger logic
operations and comparison operations to be
manipulated by deleting entries that have
already been made (for testing purposes)
each individual address can be forced, i.e.
the address does not participate in the AND
logic operation of the trigger.
SELECTION
Deletes an absolute address and the
associated comparison operation.
SELECTION
Add icon
Absolute
address
Entry of the address of a PLC variable via
STEP 7 syntax.
INPUT
DISPLAY
Data type All simple file types are supported. INPUT
DISPLAY
Note:
The addresses can be entered in German
and English notation, e.g. E1.1 or I1.1
Comment Enters a comment for the absolute address. INPUT
Add Adds the edited address to the AND logic
operation of the trigger conditions.
Notice:
The comparison operation must be entered
separately. SINUMERIK Integrate permits
saving without comparison operation. This
leaves the trigger without effect.
ACTION
"PLC Trigger" tab
The comparison operation can be edited under "PLC Trigger".
Function Description Type
PLC triggers Shows the comparison operations for the
AND logic operations in the trigger, which
can also be edited
TAB
DISPLAY
INPUT
Trigger 1
Trigger 2
...
Trigger n
The comparison operations for Trigger 1 and
Trigger 2 are logic OR.
The comparison operation consists of the
comparison operation (>, <, =, <>) and the
fixed comparison value (digit).
Notice:
SINUMERIK Integrate will not check the
plausibility of the variable address for the
potential comparison operation and actual
comparison value.
INPUT
DISPLAY
