3 Setting up functions 03/2013
3.4 Fault services
© Siemens AG 2006-2013 All Rights Reserved
3-144 SINUMERIK Integrate AMB, AMC, AMM, Function Manual (FH) - 03/2013
Function Description Type
When you select the calendar field, the calendar
opens to display the current month.
You can navigate through the months in the
calendar via the arrows. Select a number to use
the date as the start date.
The date is limited to 24 months in the future
and 24 months in the past.
If participation in common start date is selected,
you cannot make any entries here.
SELECTION
Start time The starting time for the trigger can be specified
in hours and minutes.
If no entry is made, the actual clock time that is
already pre-assigned is applied.
DISPLAY
INPUT
(Time format
with leading
zeros)
Common start
date
If participation in common start date is selected,
the time is automatically set.
Even if the common start date is subsequently
changed, it is automatically corrected.
The start date can only be selected if trigger
participates in common start date is deselected.
DISPLAY
SELECTION
(Toggle)
Next tripping
operation
To check the trigger instant, the instant in time of
the next initiation is displayed with date and
time.
DISPLAY
Type of the interval
alternatively
All
Weekly
Monthly
The type of interval must be clearly selected.
You can only select one of the three options.
DISPLAY
SELECTION
(Toggle)
All Enter a cycle 'n' in the selected time unit
- Seconds (at least 5) or
- Minutes or
- Hours or
- Days
The intervals that can be selected are restricted
to one or more days of the week, Monday to
Friday and a time window for the selected days
of the week.
The interval runs regardless of the deselect
restriction.
At the end of the interval, the trigger will be
activated in the selected time window of the day
and time.
The next interval only starts once the trigger has
been successfully triggered.
DISPLAY
INPUT
SELECTION
(1 to 99 999
minutes or
hours)
