03/2013 3 Setting up functions
3.4 Fault services
© Siemens AG 2006-2013 All Rights Reserved
SINUMERIK Integrate AMB, AMC, AMM, Function Manual (FH) - 03/2013
3-151
Function Description Type
Max. number of signaled cases per time interval
Default
configuration
The default setting is 100 cases notified/signaled
in one hour. If you select this, you cannot define
the next two parameters yourself.
DISPLAY
SELECTION
Max. number
of signaled
cases
If the default configuration is not selected, then
the number of notified/signaled cases to be
checked can be entered here, which may occur
as a maximum in the time interval specified
below without initiating this trigger.
DISPLAY
INPUT
Time interval
in minutes
If the default configuration is not selected, then
the number of error cases specified above in the
specified time interval is checked in order to
initiate this trigger.
DISPLAY
INPUT
