NOTE
Transmission using 2-wire operation was successfully tested with these settings. At higher baud rates,
problems may occur. At lower baud rates, the command S51=xx must be changed as required. The
selected baud rate must be set on both binary-signal transmitters (also see 2.6 Baud Rates and Data
Formats).
Plugs and Cables for 2-Wire Dedicated Line Operation
²
Use the supplied cables for normal dial-up operation for the 2-wire dedicated line operation.
²
Insert the cable into the dial-up plug.
If TAE boxes with N encoding are used for the connection, the lines must be connected as follows:
Table 3-2 Connection for 2-Wire Dedicated Line Operation
TAE-N 1 TAE-N 2
1 1
2 2
Application Examples
3.2 Binary-Signal Transmission Using the LOGEM928 and LGH28.8D Dedicated Line Modems
Accessories, Binary signal transmitter 2-channel, Manual 27
C53000-G9050-C607-1, Edition 09.2019
