Device Data
Auxiliary Voltage V
aux
Terminal 2-pole terminal (Phoenix)
Rated auxiliary voltage
– Direct voltage DC 24 V to 250 V
– Alternating voltage AC 110 V to 230 V/45 Hz to 65 Hz
Permissible voltage range
– Direct voltage 19 V to 300 V
– Alternating voltage 92 V to 286 V
Power consumption
– Direct voltage Max. 3 W
– Alternating voltage Max. 3.5 VA
Operating state display 1 green LED (RUN)
Fuses
Soldered in place T1.25 A
Protection class II
Structural Variant
Housing
Plastic (EC 90)
Dimensions See the outline drawings at A.2 Dimensions
Weight About 250 g
Degree of protection according to EN 60529:
– Housing IP 20; plastic
– Terminals IP 20
Safety
As per DIN EN 61010 Part 1, overvoltage category
III (AC 3.7 kVA/DC 5.2 kV)
Degree of pollution 2
Fire-resistance rating as per UL 94 V0
5.1
Technical Data
5.1 Device Data
40 Accessories, Binary signal transmitter 2-channel, Manual
C53000-G9050-C607-1, Edition 09.2019
