Ordering Data
Selection and Ordering Data
Description Variants Order No.
1 2 3 4 5 6 7 8 9 10 11 12
Optical binary signal/command transmission 7 X V 5 6 5 3 - 0 B A 0 0
Serial for 62.5 µm/125 µm multimode optical fiber up to 3 km
Auxiliary voltage, DC 24 V to 250 V and AC 110/220 V with 2
binary inputs, 2 command outputs,
Connection of the binary signal/command relay using a
terminal
Fiberglass connection for 62.5 µm/125 µm multimode optical
fiber using ST connectors
DIN-rail mounting, plastic housing
Note: For transmission using a singlemode optical fiber, the 7XV5461 is also needed. For transmission using a two-wire
control line, the 7XV5662-0AC01 is needed.
A.1
Appendix
A.1 Ordering Data
46 Accessories, Binary signal transmitter 2-channel, Manual
C53000-G9050-C607-1, Edition 09.2019
