Interfaces
Optical Interface
Optical inputs/outputs 1 transmitter, 1 receiver
Factory setting: light idle state OFF
Transmitter ST: HFBR 1404
Receiver ST: HFBR 2402S
Optical connector ST bayonet closure
Data indications
None
Wavelength 820 nm
Injected power -19 dBm, gradient fiberglass, 50 µm/125 µm
-15 dBm, gradient fiberglass, 62.5 µm/125 µm
-6.2 dBm, HCS fiber, 200 µm
Sensitivity -30 dBm
Optical budget Typically 10 dB (+3 dB system reserve)
Maximum range 3 km with gradient fiberglass, 62.5 µm/125 µm
Minimum baud rate 1200 Bd
Maximum baud rate 115 200 Bd
RS232 Interface
Connection
9-pin D-sub socket
Maximum baud rate 115 kBd
Minimum baud rate 1200 Bd
Maximum cable length 3 m
Fault-Signaling Output
Connection
Standard relay with 1 break contact; isolated; 2-
pole terminal (Phoenix)
Contact voltage (rated voltage) AC/DC 250 V
Switching power
30 W/30 VA
Switched current 5 A continuous
Fault display LED, red (ERR); continuous if device is not ready
for operation or in case of an error of the internal
power supply.
Binary Inputs
Connection
2-pole terminal (Phoenix), isolated
Contact voltage DC 24 V to 250 V/-15 %, +20 %
Current consumption (independent of voltage) Approx. 2.5 mA
Status display 1 yellow LED per input (BI-1, BI-2)
Command Outputs
Connection
Standard relays (K1, K2) with 1 make contact,
isolated, 2-pole terminal (Phoenix)
Contact voltage (rated voltage) DC/AC 250 V
5.2
Technical Data
5.2 Interfaces
Accessories, Binary signal transmitter 2-channel, Manual 41
C53000-G9050-C607-1, Edition 09.2019
