Color and Spectral Doppler
Spectral Doppler Touch Screen
Touch Screen Controls Function
Auto Stats*
Automatic trace and display of PW Doppler measurements
Select to activate / deactivate.
Select settings for data above, below or on both sides of the baseline.
Note: Available on live or frozen image.
DTI (DTI™ Doppler Tissue
Imaging Capability)
Activates the Doppler Tissue imaging feature for cardiac exams
Press to activate / deactivate.
Note: Available on live image only.
T/F Res*
(Time / Frequency
resolution)
Adjusts the balance between the temporal and frequency resolution
of the Doppler spectrum
Increase to increase temporal resolution.
Decrease to increase frequency resolution.
Note: Available on live image only.
Configurable for the soft key rotary controls and/or touch screen user interface.*
34
