Make the function check for mounted auxiliary switches according to the following
table – example switching point at 25% position:
Connection terminals
Stroke
actuator
Rotary actuator
Terminal
S1 – S3
Terminal
S1 – S2
Voltage at Y2
Y = 0 V
Actuator’s stem
retracts (until
end position is
reached)
Actuator’s spindle
turns in counter-
clockwise direction
(until end position is
reached)
- -
No voltage at Y1
und Y2
Y = 0 V
Actuator’s stem
maintains the
position
Actuator’s spindle
maintains the
position
Voltage at Y1 for
desired valve
position % + 2% x
positioning time
Example:
SAX31.00 = 27% x
120 sec = 32.5 sec
Valve
position %
+ 2%
Y = 2.7 V
Actuator’s stem
extends to
desired position
(27%)
Actuator’s spindle
turns in clockwise
direction to desired
position (27%)
Check switching point with
voltmeter
Actuator’s stem
maintains the
position
Actuator’s spindle
maintains the
position
- -
Make the function check for mounted potentiometer according to the following table
(Example values for ASZ7.5):
Connection terminals
Stroke
actuator
Rotary actuator
Terminal
P1 – P2
Terminal
P2 – P3
Voltage at Y2
Actuator’s stem
retracts (until
end position is
reached)
Actuator’s spindle
turns in counter-
clockwise direction
(until end position is
reached)
- -
No voltage at Y1 und Y2
Actuator’s stem
maintains the
position
Actuator’s spindle
maintains the
position
< 1 Ω > 996 Ω
Voltage at Y1 for desired valve
position % positioning time
Example:
SAX31.00 = 75% x 120 sec = 90
sec
Actuator’s stem
extends to
desired position
(75%)
Actuator’s spindle
turns in clockwise
direction to desired
position (75%)
- -
Check position value with
ohmmeter
Actuator’s stem
maintains the
position
Actuator’s spindle
maintains the
position
~ 560 Ω ~ 436 Ω
Voltage at Y2 for desired change
of valve position % x positioning
time
Example:
SAX31.00 = 10% x 120 sec = 12
sec
Actuator’s stem
retracts to
desired position
(65%)
Actuator’s spindle
turns in counter-
clockwise to desired
position (65%)
- -
Check position value with
ohmmeter
Actuator’s stem
maintains the
position
Actuator’s spindle
maintains the
position
~ 485 Ω ~ 511 Ω
Auxiliary switch
ASC10.51
Potentiometer ASZ7.5
