7ML19985QM82 XPS/XCT Series Transducers – OPERATION MANUAL Page EN-5
English
Specifications
* Universal flange fits ANSI, DIN, and JIS standards.
** Approximate shipping weight of transducer with standard cable length.
*** EMC performance available upon request.
XPS-10 XPS-15 XPS-30 XPS-40 XCT-8 XCT-12
Measurement
Range
0.3 - 10 m
(1 - 33 ft)
0.3 - 15 m
(1 - 50 ft)
0.6 - 30 m
(2 - 100 ft)
0.9 - 40 m
(3 -130 ft)
0.6 - 8 m
(2 - 26 ft)
0.6 - 12 m
(2 - 40 ft)
Frequency (kHz)
44 44 30 22 44 44
Beam Angle
12° 6° 6° 6° 12° 6°
Environmental
Location indoor/outdoor indoor/outdoor indoor/outdoor indoor/outdoor indoor/outdoor indoor/outdoor
Maximum
Altitude (m)
2000 2000 2000 2000 2000 2000
Ambient
Temperature
-40 to 95 °C
(-40 to 203 °F)
-40 to 95 °C
(-40 to 203 °F)
-40 to 95 °C
(-40 to 203 °F)
-40 to 95 °C
(-40 to 203 °F)
-40 to 145 °C
(-40 to 293 °F)
-40 to 145 °C
(-40 to 293 °F)
Pressure
8 bar
(120 psi)
8 bar
(120 psi)
Europe: 0.5 bar
N. America: 15
psi
Europe: 0.5 bar
N. America: 15
psi
8 bar
(120 psi)
8 bar
(120 psi)
Pollution Degree
444444
Construction
Housing
PVDF PVDF PVDF PVDF Standard: PVDF
Optional: Universal* sized
flange available with PTFE
facing
Mounting
1" NPT or
BSP conduit
connection
1" NPT or BSP
conduit
connection
1-1/2" NPT or
BSP conduit
connection
1-1/2" NPT or BSP
conduit
connection
1" NPT or BSP
conduit
connection
1" NPT or BSP
conduit
connection
Options
• factory bonded to suit ANSI, DIN, and JIS standards
• polyethylene foam facing for dusty or steamy environments
• submergence shield, where flooding can occur (available only for XPS-10, XPS-15)
• split flange for field mounting to suit ANSI, DIN, and JIS standards (not available for XPS-40)
Cable
2-wire twisted pair/braided
and foil shielded, 0.5mm² (20
AWG), PVC jacket
• 2-wire twisted pair/braided and
foil shielded, 0.5mm² (20 AWG),
PVC jacket
Maximum separation: 100 m
(330 ft)
• RG-62 A/U coax Maximum
separation: 365 m (1200 ft)
Silicon Jacket
Weight**
0.8 kg
(1.7 lb)
1.3 kg
(2.8 lb)
4.3 kg
(9.5 lb)
8 kg
(18 lb)
0.8 kg
(1.7 lb)
1.3 kg
(2.8 lb)
Maximum
Separation
365 m
(1200 ft)
365 m
(1200 ft)
365 m
(1200 ft)
365 m
(1200 ft)
365 m
(1200 ft)
365 m
(1200 ft)
Supply Source Transducers shall only be supplied by Siemens Milltronics certified controllers
Approvals
CE***, CSA, FM, CENELEC/ATEX: See nameplate or consult Siemens Milltronics for current
approvals.
