Operating Manual of FC18 Controller
Page: 30/70
12. HOW TO QUERY HISTORY
FC18 controller (interlocking) contains 11 types of history records which are alarm, trouble, supervision, activation/confirmation,
disable, test and walk-test, unconfigure equipment, unknown equipment, inconsistent equipment, exchange equipment. The
first six types support advanced query.
Steps:
1. Select a station, a line or a point and press “→” to pop out a shortcut menu,
and then press “↓” to select “History” (Fig. 11-1). Press “OK” to pop out the
record window. All the history records will be displayed. (Fig. 11-2)
Note:
If a system is selected, all history records of all stations, lines and points
belonging to this system are displayed.
If a station is selected, all history records of this station and the line and
points which belongs to this station will be displayed.
If a line is selected, all history records of this line will be displayed.
If a point is selected, all history records of this point will be displayed.
2. Press “Menu” to pop out record menu, select “Advanced Query” (Fig.11-3),
and then press “OK” to pop out advanced query window (Fig.11-4).
3. Select a type and input query time then press “OK”. All the events fulfilling
the requirements will be displayed in the window. Use “↓” /”↑” to browse
items then press “Menu”:
Select “Print” to print all the history records displayed.
Select “Quit” to return back to initial interface.
Note:
Use “↓” / “↑” to switch active window.
Use “→” to activate the dropdown menu of types.
Use “←” to delete wrong input.
Date format: YYYY-MM-DD; time format: HH-MM-SS.
0002 COMM trouble 2008-08-08 10:10:10
Interlocking Line / 01.005
Trouble
0001 Other 2008-08-08 10:10:08
Room 1008, Building 1 / 01.001.291
Property
History
History
Fig.11-1
+ 001 Disable 01.005.001
Room 1001, Building 1
2008-08-08 10:10:10
Record
+ 002 Disable 01.001.291
Room 1008, Building 1
2008-08-08 10:11:10
Fig.11-2
+ 001 Disable 01.005.001
1号楼1001室
2008-08-08 10:10:10
Record
+ 002 Disable 01.001.291
Room 1008, Building 1
2008-08-08 10:11:10
Print
Quit
Advanced Query
Fig.11-3
+ 001 Disable 01.005.001
Room 1001, Building 1
2008-08-08 10:10:10
Record
+ 002 Disable 01.001.291
Room 1008, Building 1
2008-08-08 10:11:10
Advanced Query: Type
Start Time End Time
All
2008-08-08
08:08:08
2008-08-09
10:10:10
Fig.11-4
