22. HOW TO CHECK SYSTEM
Function: To check whether the LCD, indicators, printer and the buzzer can
work normally.
Steps:
1. Press “Menu” to browse the main menu (Fig. 21-1).
Main menu displayed.
2. Press “→” to pop out the "Tool" submenu (Fig.21-2). Press "↓" to select
“Check System" and press “OK” to display the checking system window
(Fig.21-3). Press "OK" to examine the system.
- LCD: Flash in white and black once for each. It's normal if there is no
black spot.
- Indicator: All indicators flashing.
- Buzzer: Rings in 4 different sounds.
- Printer: Print "successful test!" automatically.
3. After finishing checking system, it will return to the original interface.
Fig.21-1
Fig.21-2
Fig.21-3
