Commissioning
14
Building Technologies 007828_b_en_--
Fire Safety & Security Products 09.2008
4.2 Preparation
z Control unit FC700A
– Connect mains cable and supply line (2)
– Install possible additional modules chassis and attach connection cable in ac-
cordance with the system documentation
– Set I-Bus address on all modules / set switches and jumpers
– If existing, insert EPROM on C-Bus gateway FG700A (E3H020)
– Insert all modules
– Attach I-Bus flat cable and supply cable 5V/24V on all I-Bus modules, see
chapter 5
– Connect fire control installations
– Connect batteries
z Control terminal FT700A
– Insert inscription strips
– Connect C-Bus and supply line in accordance with the system documentation
– Install terminal
z Floor repeater panels
– Set LON-Bus address / set switch
– Remove resistor if necessary
z Parallel indicator panel
– Set device address / if necessary remove resistor array
First switching-on
– Apply mains voltage, observe the safety regulations in Chapter 2
– Start-up process -> see chapter 16
4.3 Programming the system
Programming the system -> see SWE700A Online Help.
