Siemens FC700A Installation And Hardware Commissioning

Control modules
19
Building Technologies 007828_b_en_--
Fire Safety & Security Products 09.2008
9 Control modules
9.1 E3L020 Control module 'I/O'
Pos. Module Preparation Default
1 Programming switch 'S3': I-Bus address Set according to the system documentation
(1… 14)
Address 0
2 Maintenance switch 'S2': Activate test LEDs
'H1'....'H16'
Set to 'ON' for commissioning To 'OFF'
1
S3
H1
H16
2
S2
9.2 E3L030 Control module 'VdS'
Pos. Module Preparation Default
1 Programming switch 'S3': I-Bus address Set according to the system documentation
(1… 14)
Address 0
2
0Ω resistor 'X12': Configure LED4
Insert if LED4 (reserve/FBF) shall light up in
'Emergency operation'
Not inserted
3 Resistor 'R191': for SST Remove (or change) if a third-party extinguish-
ing system requiring a different value shall be
connected
Inserted 3K32
2
X12
R191
S3
1
3
