FDCIO223 S24218-B102-A1 Input / output module (transponder)
See also
Enclosed accessories [ 44]
3.2 Setup
The modules consist of the module carrier, the printed circuit board and the cover
cap. The printed circuit board includes LEDs. These indicate the status of the
inputs and outputs and the operating condition.
The cover of the printed circuit board is transparent, so that the state of the LEDs is
visible even when the housing is closed.
To protect the modules from environmental influences, the FDCH221 housing
(accessories) is available.
3.2.1 Overview
Overview
1 Cable tie holder 3 Holes for mounting feet FDCM291
2 Bores for wall mounting 4 Push button for calibrating control
lines
