4 Planning
When planning a project, proceed as follows:
1. Define the mounting site and configuration of the lines
2. Plan the various line types
‒ Collective detector line GMT
‒ Control lines
‒ Contact inputs
3. Define the values and characteristics of the fuses as well as their
mounting site
‒ 24 V supply (primary side)
‒ Outputs (secondary side)
4.1 Compatibility
The input/output module FDCIO223 is compatible with the AlgoRex, SIGMASYS,
and FS2-/FS720 fire detection systems.
For details, see 'List of compatibility'.
