Siemens FDCIO223

Planning
49
Building Technologies
0009122_e1_en_--
Fire Safety
2015-10-06
4.4 Planning the control line
Define the values of the individual parameters for the relevant inputs/outputs (see
table).
Parameters
Input/output 'I/O 1'
Input/output 'I/O 2'
Polarity of control and
monitoring systems in
relation to one another
□ Same polarity
□ Reverse polarity
□ Same polarity
□ Reverse polarity
Activation period/behavior □ Permanent
□ Only for the period of: ___ s (1 … 20 s)
□ Symmetrical pulse pattern
□ Permanent
□ Only for the period of: ___ s (1 … 20 s)
□ Symmetrical pulse pattern
Behavior in the event of a
communication problem
involving the control panel
□ Control remains the same as before the
error
□ Control is activated
□ Control is deactivated
□ 'Degraded mode horn' function (only
possible with FS20/FS720)
□ Control remains the same as before the
error
□ Control is activated
□ Control is deactivated
□ 'Degraded mode horn' function (only
possible with FS20/FS720)
4.5 Planning contact input
Define the values of the individual parameters for the relevant inputs/outputs (see
table).
Parameters
Input/output 'I/O 1'
Input/output 'I/O 2'
Type of input □ Danger input
□ Status input
□ Danger input
□ Status input
Monitored for □ Open line
□ Short circuit and open line
□ No monitoring
□ Open line
□ Short circuit and open line
□ No monitoring
Input active, when contact is □ Open
□ Closed
□ Open
□ Closed
Filter time Duration: ____s (0.5 … 240 s) Duration: ____s (0.5 … 240 s)
Notes
 The resistors must be connected at the end of the lines.
 If the inputs/outputs are configured as contact inputs, no automatic detectors or
manual call points can be connected to them.
4.6 Environmental influences
If the devices are used in industrial applications, consultation with the project
manager is required, since plastics do not withstand certain environmental
conditions.
The following factors must be taken into consideration:
 Chemicals
 Temperature
 Moisture
