4.2 Defining the mounting site and configuration of the lines
Guideline
 In humid, wet or dirty environments, use housing FDCH221.
 Use housing FDCH221 to protect the input/output module against unauthorized
access.
In clean and dry environments, you are free to install the input/output module
without any housing.
Define the type of application for the input/output module (see table).
Mounting site ________________
Mode of mounting □ Without housing
□ With housing FDCH221
Configuration of input/output
'I/O 1'
□ Siemens/Cerberus detector line, SynoLINE600
□ SynoLINE300 detector line
□ Contact input
□ Control line without confirmation
□ Inverted control
□ Reverse-polarity monitoring of control
Configuration of input/output
'I/O 2'
□ Siemens/Cerberus detector line, SynoLINE600
□ SynoLINE300 detector line
□ Contact input
□ Control line without confirmation
□ Inverted control
□ Reverse-polarity monitoring of control
Ground fault monitoring for both
inputs/outputs (jointly)
□ Yes
□ No
4.3 Planning the detector line
Define the values of the individual parameters for the relevant inputs/outputs (see
table).
Parameters
Input/output 'I/O 1'
Input/output 'I/O 2'
Detector line type □ SynoLine300
□ Siemens/Cerberus, SynoLINE600
□ Siemens/Cerberus ex line
□ SynoLine300
□ Siemens/Cerberus, SynoLINE600
□ Siemens/Cerberus ex line
Alarm verification □ No
□ Yes => alarm verification time = _____s
□ No
□ Yes => alarm verification time = _____s
End-of-line □ EOL22(Ex); obligatory in Ex area
20 V -voltage reference diode
□ EOL22(Ex); obligatory in Ex area
20 V -voltage reference diode
