6 Commissioning
The device is commissioned via the control panel. The exact procedure is
described in the control panel documentation.
Conduct a performance check once commissioning is complete.
If the input/output module is to be used for control purposes, the control lines will
need to be calibrated during commissioning.
6.1 Calibrating the control line
The input/output module must be connected correctly (inputs/outputs and
power supply).
The detector line must have been commissioned.
The input/output module must be correctly configured.
The relay must not be triggered during calibration. This is especially important
in the case of inverse controls (normal position = triggered)! Consequently,
control must be activated for calibration in the case of inverse controls!
1. Press the push button on the input/output module.
The control lines will then be calibrated. This process will take
approximately 2 s.
2. Check that calibration has been performed successfully.
Following successful calibration, the input/output module will assume
normal operation.
Notes
The control line will be recalibrated whenever the push button is pressed.
The line must be recalibrated with each new configuration.
